Specifications:
*Please note – spec applies to all sizes unless listed
separately
Frameset
Frame: 300 Series Alpha Aluminium, Internal cable routing,
3S chain keeper, T47, UDH, rack and mudguard mounts, integrated frame bag
mounts, flat-mount disc, 142x12 mm chamfered thru axle
Weight
Weight: ML – 9.87 kg/21.76 lb (with TLR sealant, no tubes)
Weight limit: This bike has a maximum total weight limit
(combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
Drivetrain
Shifter: SRAM Apex, 12 speed
Rear derailleur: SRAM Apex XPLR, 44T max cog
*Crank
Size: XS, S: SRAM Apex 1, 40T, DUB Wide, 165 mm length
Size: M, ML: SRAM Apex 1, 40T, DUB Wide, 170 mm length
Size: L, XL: SRAM Apex 1, 40T, DUB Wide, 172.5 mm
length
Bottom bracket: SRAM DUB Wide, T47 threaded, internal
bearing
Cassette: SRAM XPLR PG-1231, 11-44, 12-speed
Chain: SRAM Apex, 12-speed
Max. chainring size: 1x:44 2x: 46/30
Wheels
Hub front: Bontrager alloy, sealed bearing, CentreLock disc,
100x12 mm thru axle
Skewer front: Bontrager Switch chamfered thru axle
Hub rear: Bontrager alloy, sealed bearing, CentreLock disc,
Shimano 11-speed freehub, 142x12 mm thru axle
Skewer rear: Bontrager Switch chamfered thru axle,
removable lever
Rim: Bontrager
Paradigm 23, Tubeless Ready, 24-hole, 23 mm width, Presta valve
Spokes: 14 g stainless steel, black
Tyre: Bontrager Girona Pro, Tubeless Ready, GR puncture
protection, aramid bead, 60 tpi, 700x42 mm
Tyre part: Bontrager TLR sealant, 180 ml/6 oz
Max tyre size: 50 mm without mudguards, 42 mm with mudguards
(as measured, see manual for details)
Components
Saddle: Verse Short Comp, steel rails, 145 mm
width
Seatpost: Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm
length
*Handlebar
Size: XS, S: Bontrager Elite Gravel, alloy, 40 cm
width
Size: M, ML: Bontrager Elite Gravel, alloy, 42 cm
width
Size: L: Bontrager Elite Gravel, alloy, 44 cm
width
Size: XL: Bontrager Elite Gravel, alloy, 46 cm
width
Handlebar tape: Bontrager Supertack Perf tape
*Stem
Size: XS: Bontrager Elite, 31.8 mm,
Blendr-compatible, 7-degree, 70 mm length
Size: S, M: Bontrager Elite, 31.8 mm,
Blendr-compatible, 7-degree, 80 mm length
Size: ML, L: Bontrager Elite, 31.8 mm,
Blendr-compatible, 7-degree, 90mm length
Size: XL: Bontrager Elite, 31.8 mm,
Blendr-compatible, 7-degree, 100mm length
Brake: SRAM Apex D1 hydraulic disc, flat mount
Brake rotor: SRAM Paceline, rounded, CentreLock, 160 mm
Brake lever: SRAM Apex, 12 speed
Rotor size: Max brake rotor sizes: 180 mm front and rear
We reserve the right to make changes to the product
information contained on this site at any time without notice, including with
respect to equipment, specifications, models, colours, materials and pricing.
Due to supply chain issues, compatible parts may be substituted at any time
without notice. The prices shown are the manufacturer's suggested retail
prices.
Weights are based off pre-production products at time of
publication. Weights may vary in final production.
