Superlight, ultra-efficient and rides like a dream. This
well-rounded race bike blends industry-leading composite frame engineering with
fully integrated components to help you climb, corner and descend with
astonishing speed and sublime road handling.
Key Performance Factors
SYSTEM OPTIMIZATION
The frameset, wheels, cockpit and other parts are
engineered, developed and tested together to perform as a system. The all-new
OverDrive Aero steerer tube technology is combined with a Contact SL AeroLight
stem and Contact SL handlebar to incorporate internal cable routing that
integrates the top cap, cables and spacers in a more aerodynamic, user-friendly
setup.
WINNING EFFICIENCY
Featuring a greater stiffness-to-weight ratio than the
previous generation, along with new aero tube shaping and a lighter overall
weight, this uncompromising race bike delivers explosive acceleration and
unyielding pedaling stiffness. The result is race-winning performance in the
moments that count.
INTEGRATED AERODYNAMICS
All tube shapes are engineered and developed using
Computational Fluid Dynamics (CFD) modeling and wind-tunnel testing. From the
truncated ellipse shape of frameset tubing to a new cockpit design and
component integration, it all adds up to a more streamlined profile that
improves overall aero performance compared to the previous generation.
Specifications
|
Sizes |
S, M, M/L, L,
XL |
|
Colours |
Tech Silver |
|
Frame |
Advanced-grade
Composite, 12x142mm thru-axle, disc |
|
Fork |
Advanced
SL-grade Composite, full-composite OverDrive Aero steerer, 12x100mm
thru-axle, disc |
|
Handlebar |
Giant Contact
SL XS:420/370mm, S:420/370mm, M:440/390mm, M/L:440/390mm, L:440/390mm,
XL:440/390mm |
|
Stem |
Giant Contact
SL AeroLight XS:80mm, S:90mm, M:100mm, M/L:110mm, L:110mm, XL:120mm |
|
Seatpost |
Giant
Variant, composite, -5/+15mm offset |
|
Saddle |
Giant Fleet
SL |
|
Pedals |
PEDALS NOT
SUPPLIED |
|
Shifters |
Shimano 105
Di2 |
|
Front
Derailleur |
Shimano 105
Di2 FD-R7150 |
|
Rear
Derailleur |
Shimano 105
Di2 RD-R7150 |
|
Brakes |
Shimano 105
Di2 hydraulic, Shimano RT-CL700 rotors [F]160mm, [R]140mm |
|
Brake Levers |
Shimano 105
Di2 |
|
Cassette |
Shimano 105,
12-speed, 11x34 |
|
Chain |
KMC X12L-1 |
|
Crankset |
Shimano 105,
36/52 with Giant Power Pro power meter XS:165mm, S:165mm, M:170mm, M/L:170mm,
L:172.5mm, XL:172.5mm |
|
Bottom
Bracket |
Shimano,
press fit |
|
Rims |
Giant SLR 1
40 WheelSystem, [F]40mm, [R]40mm |
|
Hubs |
[F] Giant Low
Friction Hub, CenterLock, 12mm thru-axle, [R] Giant Low Friction Hub, 40t
ratchet driver, CenterLock, 12mm thru-axle |
|
Spokes |
Sapim |
|
Tyres |
Giant Gavia
Course 0, tubeless, 700x28c (28mm), folding |
|
Extras |
computer
mount, tubeless prepared, 33mm max tire size |
|
Max Tyre
Clearance |
33mm |
